- Busbar BBUE 4L 10 M18 NLLL+7xLN
Busbar BBUE 4L 10 M18 NLLL+7xLN
103825
8592765038265
Busbar, 4-phase, 10mm2, 63A, 18 MU, 4p Ex9CL, 7 x 1PN Ex9B
| Number of phases | 3 |
| Number of poles | 4 |
| Suitable for number of devices | 8 |
| Pitch dimensions | 18 |
| Cross section [mm²] | 10 |
| Length [mm] | 320 |
| Number of modular spacings | 18 |
| Rated permanent current Iu [A] | 63 |
| Type of electric connection | Fork |
| Insulated | Tak |
| Max. rated operation voltage Ue [V] | 400 |
| Suitable for devices with N-busbar | Tak |
| Suitable for devices with auxiliary switch | Nie |
