- Busbar BBUE 2L 10 M12 NL+10xNLPN
Busbar BBUE 2L 10 M12 NL+10xNLPN
103867
8592765038685
Busbar, 2-phase, 10mm2, 63A, 12 MU, 2P Ex9CL, 10 x 1PN Ex9PN
| Number of phases | 1 |
| Number of poles | 2 |
| Suitable for number of devices | 11 |
| Pitch dimensions | 8.7 |
| Cross section [mm²] | 10 |
| Length [mm] | 214 |
| Number of modular spacings | 12 |
| Rated permanent current Iu [A] | 63 |
| Type of electric connection | Pin |
| Insulated | Tak |
| Max. rated operation voltage Ue [V] | 230 |
| Suitable for devices with N-busbar | Tak |
| Suitable for devices with auxiliary switch | Nie |
