Contactor Ex9C115 22 3P 240V AC/DC

106218
8592765062192

Ex9C contactors are intended for various applications including heavy industrial ones. Splitting into four frame sizes brings optimization of electrical parameters and mechanical dimensions. All these frame sizes share accessory auxiliary contacts. Overload relays Ex9R differ with the frame sizes in order to fit respective contactor of given rated current. Frame size 18 contains contactors with rated currents AC-3 9, 12 and 18 A at 400 V. Size 38 consists of rated currents 25, 32, 38 A. Version 65 is split into currents 40, 50 and 65 A. Finally frame size 100 is covered with rated currents 80 and 100 A.

Znajdź sklep
Rated control supply voltage Us at AC 50 Hz [V]240
Rated control supply voltage Us at DC [V]240
Voltage type for actuatingAC/DC
Rated operation current Ie at AC-1, 400 V [A]160
Rated operation current Ie at AC-3, 400 V [A]115
Rated operation power at AC-3, 400 V [kW]55
Rated operation current Ie at AC-4, 400 V [A]54
Rated operation power at AC-4, 400 V [kW]30
Modular versionNie
Number of auxiliary contacts as normally open contact2
Number of auxiliary contacts as normally closed contact2
Type of electrical connection of main circuitBolt connection
Number of normally closed contacts as main contact0
Number of main contacts as normally open contact3
Power loss [W]
