Kontaktori Ex9C115 22 3P 220V AC/DC
106220
8592765062215
Kontaktori Ex9C dizajnirani su za nominalne struje od 115 do 1450A u AC-3 režimu. Pogodni su za širok spektar aplikacija u industriji, uključujući i one najzahtevnije. Dostupni su u 6 veličina kućišta, što omogućava optimizovane električne karakteristike i kompaktne mehaničke dimenzije. Moguć je širok opseg dodatne opreme koji je kompatibilan sa svih 6 veličina kućišta. Serija Ex9C poseduje kontrolisan upravljački namotaj što osigurava da se potrošnja značajno smanji kada je kontaktor "zatvoren". Ex9R bimetali su usklađeni sa odgovarajućim kontaktorom za datu nominalnu struju, sve do veličine kućišta Ex9C500.
| Rated control supply voltage Us at AC 50 Hz [V] | 220 |
| Rated control supply voltage Us at DC [V] | 220 |
| Voltage type for actuating | AC/DC |
| Rated operation current Ie at AC-1, 400 V [A] | 160 |
| Rated operation current Ie at AC-3, 400 V [A] | 115 |
| Rated operation power at AC-3, 400 V [kW] | 55 |
| Rated operation current Ie at AC-4, 400 V [A] | 54 |
| Rated operation power at AC-4, 400 V [kW] | 30 |
| Modular version | Nie |
| Number of auxiliary contacts as normally open contact | 2 |
| Number of auxiliary contacts as normally closed contact | 2 |
| Type of electrical connection of main circuit | Vijčani spoj |
| Number of normally closed contacts as main contact | 0 |
| Number of main contacts as normally open contact | 3 |
| Power loss [W] | 2.115 |
