- Contactor Ex9C265 22 3P 400V AC/DC
Contactor Ex9C265 22 3P 400V AC/DC
106262
8592765062635
Ex9C contactors, designed for rated currents from 115 up to 1450 A in AC-3 category, are suitable for a wide range of industrial applications, including heavy industrial use. They are available in six frame sizes, allowing for optimized electrical performance and compact mechanical dimensions. Auxiliary contact is available as accessory for all frame sizes. The contactors come with a controlled coil, which ensures that power consumption is significantly reduced when contactor is closed. Ex9R overload relays are matched to the respective contactor for the given rated current, up to frame size Ex9C500.
| Rated control supply voltage Us at AC 50 Hz [V] | 400 |
| Rated control supply voltage Us at DC [V] | 400 |
| Voltage type for actuating | AC/DC |
| Rated operation current Ie at AC-1, 400 V [A] | 300 |
| Rated operation current Ie at AC-3, 400 V [A] | 265 |
| Rated operation power at AC-3, 400 V [kW] | 132 |
| Rated operation current Ie at AC-4, 400 V [A] | 117 |
| Rated operation power at AC-4, 400 V [kW] | 63 |
| Modular version | Nie |
| Number of auxiliary contacts as normally open contact | 2 |
| Number of auxiliary contacts as normally closed contact | 2 |
| Type of electrical connection of main circuit | Bolt connection |
| Number of normally closed contacts as main contact | 0 |
| Number of main contacts as normally open contact | 3 |
| Power loss [W] | 2.265 |
