| Rated permanent current Iu [A] | 2000 |
| Rated voltage [V] | 800 |
| Rated short-circuit breaking capacity Icu at 400 V, 50 Hz [kA] | 65 |
| Overload release current setting [A] | 800-2000 |
| Adjustment range undelayed short-circuit release [A] | 4000-30000 |
| Integrated earth fault protection | Nie |
| Type of electrical connection of main circuit | Other |
| Device construction | Built-in device slide-in technique (withdrawable) |
| Suitable for DIN rail (top hat rail) mounting | Nie |
| DIN rail (top hat rail) mounting optional | Nie |
| Switched-off indicator available | Tak |
| With integrated under voltage release | Nie |
| Number of poles | 3 |
| Position of connection for main current circuit | Back side |
| Type of control element | Push button |
| Complete device with protection unit | Nie |
| Motor drive integrated | Nie |
| Motor drive optional | Tak |
| Degree of protection (IP) | IP40 |
