| Switching function | Group switch |
| Number of normally open contacts | 0 |
| Number of normally closed contacts | 0 |
| Number of change-over contacts | 4 |
| Number of poles | 4 |
| Nominal rated current [A] | 16 |
| Nominal rated voltage [V] | 400 |
| Rated switching capacity [kA] | - |
| Short-circuit breaking capacity (Icw) [kA] | - |
| Voltage type | AC |
| Forced segregation (according to DIN VDE 0113) | Nie |
| With signal lamp | Nie |
| Colour calotte | Green |
| Width in number of modular spacings | 4 |
| Built-in depth [mm] | 75 |
| Degree of protection (IP) | IP20 |
| Power loss [W] | 1.2 |
