Ex9L-H residual current circuit breakers are suitable for domestic as well as industrial applications. They are based on electromagnetic principle. It brings the advantage of voltage independent function. Adequate voltage is only necessary when testing the RCCB with the test button. Magnetic RCCBs should be tested regularly with a period of one month.

Mounting instruction Ex9L

Datasheet Ex9L-H Type F

EU Declaration of conformity Ex9L-H Type F

Catalogue Installation Devices

Residual Current Circuit Breaker Ex9L-H 2P 40A F 30mA

Number of poles (total)

Nominal rated voltage [V]

Nominal rated current [A]

Rated fault current [A]

Mounting method

Leakage current type

Selective protection

Short-circuit breaking capacity (Icw) [kA]

Surge current capacity [kA]

Frequency

Additional equipment possible

Degree of protection (IP)

Construction size (in accordance with DIN 43880)

Width in number of modular spacings

Built-in depth [mm]

Short-time delayed tripping

Power loss [W]

Number of poles (total)	2
Nominal rated voltage [V]	230/240
Nominal rated current [A]	40
Rated fault current [A]	0.03
Mounting method	DIN rail
Leakage current type	F
Selective protection	Nie
Short-circuit breaking capacity (Icw) [kA]	10
Surge current capacity [kA]	3
Frequency	50 Hz
Additional equipment possible	Nie
Degree of protection (IP)	IP20
Construction size (in accordance with DIN 43880)	2
Width in number of modular spacings	2
Built-in depth [mm]	79
Short-time delayed tripping	Nie
Power loss [W]	7.2
