Silent instalation contactor Ex9CH63H 20 48V AC/DC

117201
8592765172013

The Ex9CHH installation contactors are designed for use in household and building modular distribution boards. These contactors are primarily utilized in building automation systems for the switching and control of lighting, heating systems, ventilation, pumps, heat pumps, and other applications. The silent operation of these contactors makes them particularly well-suited for environments where noise reduction is critical, such as offices and residential settings. Additionally, their AC/DC control voltage capabilities meet higher technical demands, ensuring dependable operation in more demanding scenarios.

Rated operating voltage [V]230 - 400
Rated operation current [A]63
Utility category1
Rated excitation voltage [V]48
Voltage type (operating voltage)AC
Voltage type (excitation voltage)AC/DC
Number of normally open contacts2
Number of normally closed contacts0
Slider for hand switchNie
Number of modular spacings2
Built-in depth [mm]67.5
Additional equipment possibleTak
Degree of protection (IP)IP20
Width in number of modular spacings2
Power loss [W]
